Heavy Duty Electric Hydraulic Roll Grooving Machine for Steel Pipe SCH10/SCH40 2"-16"(RG-6X)

KeyWords

Heavy Duty Electric Hydraulic Roll Grooving Machine for Steel Pipe SCH10/SCH40 2"-16"(RG-6X)

roll groovers are designed to improve speed and efficiency for fire sprinkler and other industrial installations

Grooving Capacity: 2"-16"

Max Wall Thickness: 10mm

Power Supply: 1100W

Output Speed: 23RPM

Contact Now

Favorites

Detail Information

2"-16" Heavy Duty Electric Hydraulic Roll Groover

Welping 1600mm hydraulic butt fusion machine

Model RG-6X Electric Hydraulic Roll Grooving Machine is designed to roll grooves on steel pipes and Stainless Steel from 2"-16" (DN50~DN400) SCH10 / SCH40.

The compact large-sized groove machine boasts exceptional versatility and robust performance. Its wide working size range and heavy-duty adjustable bracket make it suitable for pipes of

varying sizes.

Special designed roller set prevents flare on the pipe ends, eases the installation of the grooved couplings.

Inbuilt high-performace gear reducing motor contributes compact size and low noise.

The unique split-type hydraulic system prevents oil leak and extends service life. Groove depth lock nut ensure high quality grooves and high efficiency.

PARAMETER

Mode	RG-6X
Suitable materials	Carbon Steel,Stainless Steel
Grooving Capacity	for 2"-16" steel pipe SCH10/SCH40
Power supply	220V/110V
Frequency	50HZ /60HZ
Max wall thickness	10mm
Motor power	1100W
Output speed	23RPM
Packing gross weight	170kgs
Packing size	924887cm

ORDERING INFORMATION

Catalog Number	Phase	Power	Voltage/Frequency
900060	Single	1100W	220V,50/60HZ
900061	Single	1100W	110V,50/60HZ

STANDARD PARTS

Item Number	Description	Net weight
911022	Drive roller 2"-3" (φ60~φ89)	1.30kg
911021	Drive roller 3 1/2"-6" (φ101~φ168)	1.30kg
911020	Drive roller 8"-12" (φ219~φ325)	1.40kg
911143	Drive roller 14"-16"(φ355~φ426)	1.60kg
912010	Groove roller 2"- 3" (φ60~φ89)	0.450kg
912009	Groove roller 3 ½" -6" (φ101-φ168)	0.45kg
912008	Groove roller 8"-12"(φ219~φ325)	0.45kg
912052	Groove roller 14"-16"(φ355~φ426)	0.45kg
998103	Pipe stand for 1"-12"	33.0kg
998026	Foot switch	1.50kg

PRODUCT DETAILS MAP

Pipe Stand

for 2"-16" steel pipe

Drive Roller

one set 2"-3" (φ60~φ89)

one set 3 ½"-6" (φ101~φ168)

one set 8"-12"(φ219~φ325)

one set 14"-16"(φ355~φ426)

_{Groove roller}

one set 2"-3" (φ60~φ89)

one set 3 ½"-6" (φ101~φ168)

one set 8"-12"(φ219~φ325)

one set 14"-16"(φ355~φ426)

Foot Switch
