Portable Pipe Cold Cutting Beveling Machine pipe beveling cutting machine

Portable Pipe Cold Cutting Beveling Machine pipe beveling cutting machine

Portable Pipe Cold Cutting Beveling Machine pipe beveling cutting machine
Portable Pipe Cold Cutting Beveling Machine pipe beveling cutting machinePortable Pipe Cold Cutting Beveling Machine pipe beveling cutting machinePortable Pipe Cold Cutting Beveling Machine pipe beveling cutting machinePortable Pipe Cold Cutting Beveling Machine pipe beveling cutting machinePortable Pipe Cold Cutting Beveling Machine pipe beveling cutting machine
designed for groove processing of narrow working space and small diameter pipeline section.
Color
green or blue
Volate
220V/110V
Application material
Stainless steel,alloy steel,carbon steel
Beveling capacity
25-1830mm
Beveling method
Od-mounted type
Beveling type
U,single V, double V,J-type
Detail Information
INTRODUCTION
Portable Pipe Cold Cutting Beveling Machine
DETAILS
Pipe beveling cutting machine are external clamping full automatic beveling machine with compact design concept,which is designed for groove processing of narrow working space and small diameter pipeline section. The external clamping type positioning installation is adopted and each specification and diameter pipe has a corresponding tensioning block which is automatic centering ,firm clamping and convenient operation. It is widely use in pipeline installation engineering .


FEATURES

●Light weight and easy carry. ●Modular design. ●Cold cutting without changing the pipe material. ●Can work on stainless steel,carbon steel,carbon steel,alloy steel and other multi specification materials,u,single V,double V,J-type weld groove,chamfer and flat mouth,and groove processing of convex flange and plane flange after butt fusion welding,light weight and easy carry.
STANDARD ACCESSORIES
Machine body
1 Set
Cutting blade
2 pc 0°,1 pc 30°,1 pc 37.5°
Water Spray
1 Pc
Tool box  with wrenches
1 Set
Portable Pipe Cold Cutting Beveling Machine
Portable Pipe Cold Cutting Beveling Machine
Portable Pipe Cold Cutting Beveling Machine
Portable Pipe Cold Cutting Beveling Machine
 PARAMETER
Model No.
Capacity OD  (mm)
Capacity OD  (inch)
Wall thickness  (mm)
Standard
Wall thickness  (mm)
Heavy duty
Roating speed   (RPM)
WPOE-89
25-89
1"-3"
≤30
/
42
WPOE-168
50-168
2"-6"
≤30
≤50
20
WPOE-230
80-230
3"-8"
≤30
≤50
15
WPOE-275
125-275
5"-10"
≤30
≤70
15
WPOE-305
150-305
6"-10"
≤30
≤110
13
WPOE-325
168-325
6"-12"
≤30
≤110
13
WPOE-377
219-377
8"-14"
≤30
≤110
13
WPOE-426
273-426
10"-16"
≤30
≤110
12
WPOE-457
323-457
12"-18"
≤30
≤110
12
WPOE-508
355-508
14"-20"
≤30
≤110
11
WPOE-560
400-560
16"-22"
≤30
≤110
11
WPOE-610
457-610
18"-24"
≤30
≤110
11
WPOE-630
480-630
20"-24"
≤30
≤110
11
WPOE-660
508-660
20"-26"
≤30
≤110
11
WPOE-715
560-715
22"-28"
≤30
≤110
10
WPOE-762
610-762
24"-30"
≤30
≤110
10
WPOE-830
660-830
26"-32"
≤30
≤110
10
WPOE-914
762-914
30"-36"
≤30
≤110
10
WPOE-1066
914-1066
36"-42"
≤30
≤110
9
WPOE-1230
1066-1230
42"-48"
≤30
≤110
9
WPOE-1430
1219-1430
48"-56"
≤30
≤110
8
WPOE-1630
1422-1630
56"-64"
≤30
≤110
7
WPOE-1830
1630-1830
64"-72"
≤30
≤110
6
 PRODUCT DETAILS MAP
Portable Pipe Cold Cutting Beveling Machine
Inward expansion type
Complete cooling process without changing the material of tube.
Rension installatiom
0-37 degree tool to beveling the pipe Fast speed and high efficiency

Portable Pipe Cold Cutting Beveling Machine
Portable Pipe Cold Cutting Beveling Machine
Cutting tool
0°,30°,37.5° is standard tools ,other size optional.
Portable Pipe Cold Cutting Beveling Machine
Portable Pipe Cold Cutting Beveling Machine
Portable Pipe Cold Cutting Beveling Machine
Standard blade
Wall thickness 30mm
Portable Pipe Cold Cutting Beveling Machine
Heavy duty blade
Wall thickness 110mm
Portable Pipe Cold Cutting Beveling Machine
DOWNLOAD
Welping E-Catalog of Pipe Beveling Cutting Machine
Operational Manual of Pipe Beveling Cutting Machine
Warranty Certificate of Pipe Beveling Cutting Machine
