Automatic Metal Side steel plate Milling Cutter

Automatic Metal Side steel plate Milling Cutter

Automatic Metal Side steel plate Milling Cutter
Automatic Metal Side steel plate Milling CutterAutomatic Metal Side steel plate Milling CutterAutomatic Metal Side steel plate Milling CutterAutomatic Metal Side steel plate Milling CutterAutomatic Metal Side steel plate Milling Cutter
The milling machine equiped with commonly used CNC blades to make the customers use the costs more cheaply.
Color
Silver
Volate
AC380V/50hz
Application material
Stainless steel,alloy steel,carbon steel,Composite
Clamp thickness
6-60mm
Spindle Speed
0-1500r/min (adjustable)
Bevel Angle
0-90° (adjustable)
Power
3400w
Detail Information
INTRODUCTION
plate cutting machine
DETAILS
WP-60L Pipe plate Milling Machines can adjust from 0° to 90° Rear-mounted speed reducer is good for processing narrow plate, and it is safer Special separate design of Control Box and electrical carbinet make the operation safer Adopt multiply-cutting blades head to process plate beveled edge, therefore the milling speed of each blade is faster and easier. The surface roughness of plate beveling face can reach to Ra3.2~6.3, it can complete meet the welding demand of pressure vessel Small in Size, light in weight Cold milling method does not affect the material property, no oxidation in beveled surface.


FEATURES

WP-60L edge milling machine convenient and simple operation. The finish of groove is as high as Ra3.2-6.3. The milling machine equiped with commonly used CNC blades to make the customers use the costs more cheaply.

STANDARD ACCESSORIES
Machine body
1 Set
Blade
1 pc
Tool box  with wrenches
1 Set
Pipe plate Milling Machine
Pipe plate Milling Machine
Pipe plate Milling Machine
Pipe plate Milling Machine
 PARAMETER
Plate cutting machine
Power
AC 380V/50hz
Clamp thickness
6-40mm
Total
3400W
Clamp width
>80mm
Spindle Speed
1050r/min
Clamp Length
>300mm
Feed Speed
0-1500r/min
(adjustable)
Work Height
820-860mm
Bevel Wdith
1-45mm
Processing
materials
Carbon Steel

Single Bevel Width
1-15mm
Stainless Steel
Bevel Angle
0-90°
Aluminum alloy
Automatic clamping (optional)
Composite Plate
 PRODUCT DETAILS MAP
Pipe Beveling Machines
Handle Wheel
Adjust Feed Volume
CNC Cutter
High Precision

Pipe Beveling Machines
Pipe Beveling Machines
New Type Cutter
More accurate when processing 90°
Angle Scale
Adjust Bevel Angle

Pipe Beveling Machines
Pipe Beveling Machines
Rubber Wheel Clamp
More tighter Protect plate surface not damage
CNC Displayer
Accurate Adjust Feed Speed
Equip with Manual clamp
Auto clamp function is optional
Pipe Beveling Machines
Pipe Beveling Machines
Pipe Beveling Machines
Pipe Beveling Machines
Pipe Beveling Machines
