Hydraulic Manual Roll Groover for Steel Pipe SCH10/SCH40 2"-12 "(RG-H2X)
Hydraulic Manual Roll Groover for Steel Pipe SCH10/SCH40 2"-12 "(RG-H2X)
roll groovers are designed to improve speed and efficiency for fire sprinkler and other industrial installations
- Grooving Capacity
- 2"-12"
- Max Wall Thickness
- 10mm
- Gross weight
- 67kg
Detail Information
2"-12" hydraulic manual groove rolling machine
The Model RG-H2X manual hydraulic roll grooving assembly is designed for grooving steel pipe with an installed power drive or horizontal tapping machine
It is a lightweight tool for grooving steel pipes from 2" to 12" (DN50~DN300)
Compact design and robust construction enable the unit to perform large-scale manufacturing tasks on the job
The unique combination of hydraulic feed pump and trough depth locking knob guarantees a quality trough and optimal efficiency.
scope
|
model
|
RG-H2X
|
|
Applicable materials
|
Carbon steel, stainless steel
|
Capacity | 2"-12" SCH10/40 |
Maximum wall thickness | 10mm |
Packaging gross weight | 67kg |
Package Size | 45*20*65cm |
Ordering Information
|
catalog number
|
describe
|
net weight
|
Package Size
|
|
900003
|
2-12" Manual Grooving Machine
|
67kg
|
45*20*65cm
|
Standard Parts
|
Item Number
|
describe
|
net weight
|
|
|
911022
|
Driving roller 2"- 3" (φ60~φ89)
|
1.3 kg
|
|
911021 | Drive roller 3 1/2"-6" (φ101-φ168) | 1.30KG | |
|
911020
|
Drive roller 8"-12" (φ219- φ325)
|
1.3 kg
|
|
912010 | Grooved roller 2"- 3" (φ60~φ89) | 0.45kg | |
912009 | Groove roller 3 1/2"-6"(φ101-φ168) | 0.45kg | |
912008 | Grooved roller 8"-12"(φ219 -φ325) | 0.45kg | |
911018 | drive rod adapter | 2.3 kg | |
913006 | support stool | 2.2kg | |
Product details picture
drive roller
A set of 2"- 3" (φ60~φ89)
one set 3 1/2"-6" (φ100-φ168)
A set of 8"-12"(φ219-φ325)
Troughed roller
A set of 2"- 3" (φ60~φ89)
one set 3 1/2"-6" (φ100-φ168)
A set of 8"-12"(φ219-φ325)
Support Bench for Tapping Machines - 2", 2 1/2", 3", 4" Tapping Machines
Ratchet with sleeve
Support platform
