Manual Butt Fusion Machine 90mm to 250mm for HDPE Pipes

Manual Butt Fusion Machine 90mm to 250mm for HDPE Pipes

Manual Butt Fusion Machine 90mm to 250mm for HDPE Pipes
Manual Butt Fusion Machine 90mm to 250mm for HDPE PipesManual Butt Fusion Machine 90mm to 250mm for HDPE PipesManual Butt Fusion Machine 90mm to 250mm for HDPE PipesManual Butt Fusion Machine 90mm to 250mm for HDPE Pipes
Rugged and reliable, the 90mm to 250mm manual HDPE butt fusion machine are lightweight and require only one operator
Lead Time
7-15 days once order confirmed
Terms of Payment
T/T, Western Union, Paypal,X Transfer
FOB Port
Shanghai, Ningbo
Certificate
CE
MOQ
1 Set
Business type
fusion equipment manufacturer
Detail Information
Manual Butt Fusion Machine 90mm to 250mm for HDPE Pipes
Welping 200mm Manul butt fusion machine
DETAILS
This small manual Butt fusion machine provides standard welding range of 90mm to 250mm, with unique gear transmission structure. mainly consists of 2 major parts: Carriage (also called frame or base), planing tool (also called trimmer or facer) and heater. Carriage for precise face joint and steady pipe clamping, planing tool and heater responsible for accurate trimming and heating. It's an effective, trouble free connecting for PE, PP, PVDF pipes.

FEATURES
※ Robust structure of carriage part with streamline outlook ※ Swivel handle with gear transmission of extremely smooth operating structure ※ Durable copper wiring motor, HSS blade, PTFE coating from Dupont or Daikin
STANDARD ACCESSORIES
Main Frame
1 Set
Heating Plate
1 Set
Trimmer
1 Set
Reducers
1 Set
Tool Box
1 Set
160mm manual butt fusion machine
160mm butt welding machine
160mm pipe jointing machine
160mm HDPE pipe welding machine
 PARAMETER
Welping 200mm butt fusion machine
Mode
WP250C
Suitable materials
 PE,PP, PB. PVDF
Range
90-110-125-140-160-180-200-225-250mm
Power supply
 110V/220V
Frequency
50HZ
Total power
3.4 KW
Heating plate
2.3 KW
Planing tool
 1.1 KW
Max.Temperature of heating plate
270ºC
Temp.Deviation in Surface
 ±5ºC
Total Weight
105kg
Net weight
90kg
Packing Size
81*59*66cm
 PRODUCT DETAILS MAP
160mm butt fusion machien frame
Basic Frame
· Complete welded frame structure, steady and robust
· Hand-wheel driving, simple and convenient
· Chromated integral shaft made of1045(ASTM)/S45C(JIS)/C45(DIN) steel
· Base made of Q235 steel with spraying treatment
· Cast aluminum clamps, sandblasting &
  Spraying treatment
Planning tool
· HSS blade with double edge
· Casting aluminum trimmer plate, durable and anti-corrosion
· Gear transmission instead of chain
· Motor with pure copper wiring
planning tool for butt fusion machine
heating plate of butt fusion machine
Heating Plate
- Teflon Coating from Japan - Thermocouple sensor - Bakelite handle - Digtal display
Reducers
90-110-125-140-160-180-200-225-250mm reducers
reducers of butt fusion machine
DOWNLOAD
Welping E-Catalog of Butt Fusion Machine
Breakdown Part List of Manual Butt Fusion Machine
Operational Manual of Manual Butt Fusion Machine
Warranty Certificate of Butt Fusion Machine
